• 1-15415847-1 1-15415848-1 High Pressure Tube HITACHI Excavator Spare Parts For EX200-3C

• Specification

Name	High Pressure Tube
Parts No	1-15415847-1 1-15415848-1
Machine Model	225CL RTS JD 270C LC JD EX200-3C
Category	Fuel Injection System
Lead time	1-3 DAYS
Quality	Brand new, OEM quality
MOQ	1 PCS
Means of transport	By sea/air, DHL FEDEX UPS TNT EMS
Packing	As request or standard packing

• Compatible models

• More other tube parts fit for HITACHI machine

5154112231 PIPE; JOINT

135C RTS JD, 225CL RTS JD, 270C LC JD, 330C LC JD, 370C JD, 470G LC, 600C LC JD, 670G LC, 870G LC, CD1500, CD2000, CG45, CP215, CP220-3, CX1000, CX1000-C, CX1100, CX1800, CX2000, CX650-2, DX40-C, DX40...

1154124711 PIPE; INJ NOZZLE LEAK OFF

225CL RTS JD, 270C LC JD, CG45, EX100W, EX100WD, EX125WD-5, EX160WD, EX200, EX200-2, EX200-3, EX200-3C, EX200-3E, EX200-5, EX200-5 JPN, EX200-5HG, EX200-5HHE, EX200-5LV JAP, EX200-5X JPN, EX200-5Z JPN...

8085988 PIPE

ZX270, ZX270-3, ZX280LC-3, ZX280LC-3-HCME, ZX280LCH-3, ZX280LCN-3FAMS, ZX280LCN-3FHCME, ZX290LC-5B, ZX290LCN-5B, ZX330-3, ZX330-3F, ZX350-3-AMS, ZX350H-3, ZX350H-3F, ZX350K-3, ZX350K-3F, ZX350LC-3-HCM...

8097025 PIPE

ZR130HC

9772747 PIPE

ZX240-5G, ZX240LC-5G, ZX250H-5G, ZX250K-5G, ZX250LC-5B, ZX250LCH-5G, ZX250LCK-5G, ZX250LCN-5B

0927502 PIPE

ZX230, ZX240H, ZX240K, ZX250-AMS, ZX250-HCME

8094198 PIPE

270C LC JD, ZX270, ZX280LC-AMS, ZX280LC-HCME

8103601 PIPE;RETURN

UCX300

9763245 PIPE

ZX300W

26488-47081 PIPE

LX110-7

8069283 PIPE;SUCTION

EX200-5 JPN, EX220-5 JPN

• Catalog parts list

Pos.	Part No	Qty	Parts name	Comments
001(A).	1156029920	[1]	PUMP ASM; INJ	SEE FIG-NO 0-80 - 0-85 FOR COMPONENT.
3	9091505080	[7]	WASHER; LK,INJ PUMP	ID=8.2
004(B).	9091605080	[7]	WASHER; INJ PUMP	ID=8.4
004(B).	916105080	[7]	WASHER; INJ PUMP	ID=8.4
007(C).	108108600	[7]	BOLT; INJ PUMP BRKT	A M8X60
007(C).	108058600	[7]	BOLT; INJ PUMP BRKT	M8X60
011(B).	9091505100	[1]	WASHER; INJ PUMP BRKT	ID=10.2
015(A).	1157801680	[1]	COUPLING ASM; INJ PUMP	SEE FIG-NO 0-87 FOR COMPONENT.
016(B).	1154158471	[1]	PIPE; INJ NO.1
017(B).	1154158481	[1]	PIPE; INJ NO.2
018(B).	1154158491	[1]	PIPE; INJ NO.3
019(B).	1154158501	[1]	PIPE; INJ NO.4
020(B).	1154158512	[1]	PIPE; INJ NO.5
021(B).	1154158522	[1]	PIPE; INJ NO.6
31	1153003310	[6]	NOZZLE ASM; INJ
032(A).	8970161471	[6]	HOLDER ASM; NOZZLE
33	1153112630	[6]	NOZZLE; INJ
34	1153390090	[6]	BOLT; EYE,NOZZLE HOLDER
35	1153320170	[6]	NUT; NOZZLE RET,NOZZLE HOLDER
36	1153390100	[12]	GASKET; RETURN PIPE,NOZZLE HOLDER	ALSO INCLUDED IN GASKET SET(ENGINE)
36	1096300820	[12]	GASKET; RETURN PIPE,NOZZLE HOLDER	ID=8.2 OD=13.2<BR>ALSO INCLUDED IN GASKET SET(ENGINE)
37	5153320060	[6]	NUT; CAP,NOZZLE HOLDER
37	5153320060	[6]	NUT; CAP,NOZZLE HOLDER
38	5153390600	[6]	GASKET; CAP NUT,NOZZLE HOLDER
39	8941695030	[6]	SCREW; ADJ,NOZZLE SPRING,NOZZLE HOLDER
39	8941695030	[6]	SCREW; ADJ,NOZZLE SPRING,NOZZLE HOLDER
41	8943203080	[6]	CONNECTOR; FUEL INL,NOZZLE HOLDER
42	5153390030	[6]	GASKET; INL CONNECTOR,NOZZLE HOLDER
44	5153430050	[6]	SPRING; NOZZLE,NOZZLE HOLDER
45	8941695020	[6]	ROD; PUSH,NOZZLE HOLDER
45	8941695020	[6]	ROD; PUSH,NOZZLE HOLDER
54	9153390510	[6]	COVER; DUST,NOZZLE HOLDER
60	9091505080	[12]	WASHER; NOZZLE HOLDER	ID=8.2
60	915105080	[12]	WASHER; NOZZLE HOLDER	ID=8.2
62	9091104080	[12]	NUT; NOZZLE HOLDER	M8
62	911105080	[12]	NUT; NOZZLE HOLDER	M8
66	5153150030	[6]	GASKET; INJ NOZZLE	ID=9.2 OD=19.0 T=7.3<BR>ALSO INCLUDED IN GASKET SET(ENGINE)
075(A).	9091607100	[3]	WASHER; PL,BRKT TO INJ PUMP	ID=10 OD=26
78	500410200	[2]	BOLT; BRKT TO C/BL	M10X20 W/LK WASHER
78	505410200	[2]	BOLT; BRKT TO C/BL	M10X20 W/LK WASHER
79	9091104100	[1]	NUT; BRKT TO INJ PUMP	M10
79	9091104100	[1]	NUT; BRKT TO INJ PUMP	M10
080(A).	5197510042	[1]	BRACKET; PUMP
080(A).	5197510042	[1]	BRACKET; PUMP
82	9091505100	[2]	WASHER; LK,BRKT TO C/BL	ID=10.2
85	8943706751	[1]	GASKET; BRKT,INJ PUMP
98	9154196130	[6]	CLIP; "A",INJ PIPE
99	9098025390	[6]	BOLT; CLIP,INJ,PIPE	M5X20
114	9154196120	[6]	CLIP; INJ PIPE
115	9154196140	[6]	CLIP; "B",INJ PIPE
133	1154124711	[1]	PIPE; INJ NOZZLE LEAK OFF
133	1154124711	[1]	PIPE; INJ NOZZLE LEAK OFF
134	1096750371	[1]	BOLT; JOINT,LEAK OFF PIPE	M8X18 FLANGE
135	1096300820	[2]	GASKET; JOINT BOLT,LEAK OFF PIPE	ID=8.2 OD=13.2<BR>ALSO INCLUDED IN GASKET SET(ENGINE)
